Administrators can rely on the dependability and scalability offered by Dell’s PowerEdge line of servers, and the Dell PowerEdge R620 server is no exception. With powerful Intel Xeon E5-2600 processors, this system is designed for handling virtualization, work group collaboration, and high performance computing with ease.
Intel’s C602 chipset supports one, or a maximum of two Intel Xeon E5-2600 or E5-2600 v2 processors with up to 12 cores each. The Xeon E5-2600 v2 processors offer up to 40% greater performance compared to the previous generation E5-2600 processors. Administrators can start out with just one processor, and quickly scale to support two processors as business needs change. Dell’s suite of management tools including OpenManage and iDRAC7 make it easy for administrators to manage the system on site or remotely out of band. Choose from 495W, 750W or 1100W platinum power supplies.
The Dell R620 server supports a maximum of 10TB of storage using 10 x 2.5-inch drives. SAS, SATA HDD or SSD drives are compatible with the system. An alternate configuration supports four hot-plug SAS, SATA HDDs or SSDs plus two PCIe SSDs. Nearline SAS/ SATA and self-encrypting drives are also supported on the R620. The chassis that cannot be reconfigured after purchase to support the other configuration, so choose wisely. The R620 also supports a failsafe hypervisor with the addition of an optional dual SD module with one card in mirror mode.
With two processors, the system supports 24 DDR3 registered DIMM (RDIMM), unbuffered DIMM (UDIMM), or load reduced DIMM (LRDIMM) memory modules. Using 24 64GB LRDIMM memory modules with two processors will enable up to 1.5TB of total memory and transfer speeds of up to 1866MHz when paired with a compatible E5-2600 v2 processor. Transfer speeds will default to the slowest performer between the memory and CPU.
Depending on your choice of chassis configuration, this server will support two or three PCIe 3.0 expansion slots. The ten-bay system is available only with a three PCIe slot option. Dell’s flexible NIC technology allows administrators to choose a network fabric technology to support their work flow and I/O performance without using one of the PCIe slots on the system board. This leaves expansion slots to be filled with additional NICs to increase I/O bandwidth, optional PERC8 RAID controllers for increased performance, or GPUs for enhanced processing. The integrated software RAID controller supports RAID 0, 1, 5, and 10. For more RAID options, administrators can choose from several PERC8 controllers that support the full range of RAID options.
iDRAC7 and OpenManage Essentials are standard equipment on this system, granting administrators out of band access to the hardware on site or remotely using a standard browser. Upgrading to iDRAC7 Express or Enterprise can be done with the purchase of a license key and provides administrators with more management tools.
The Dell PowerEdge R620 rack server is an impressive general purpose platform that can be applied to a wide range of applications. With its small footprint and powerful performance, it’s a perfect fit in a space constrained data center. It features a number of Dell’s RAS (Reliability, Availability, and Serviceability) features including hot-pluggable drives, power supplies and fans, along with a redundant hypervisor and easy to use embedded management features.
Dell PowerEdge R620 Server – Specifications
PROCESSOR – 2 SOCKETS
Intel® Xeon® processor E5-2600 or E5-2600 v2 product families
Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V®)
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux®
Virtualization options:
Citrix® XenServer®
VMware® vSphere® ESXi™
Red Hat Enterprise Virtualization®
CHIPSET
Intel® C602
MEMORY
Up to 1.5TB
Up to 1866MT/s DDR3
24 DIMM slots (12 DIMMs per CPU)
STORAGE
Maximum internal storage:
Up to 10TB
Hot-plug hard drive options:
2.5” PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K), SAS 512n (15K)
Self-encrypting drives available
DRIVE BAYS
Up to 10 2.5” hot-plug SAS, SATA, or SSD
Up to 4 hot-plug 2.5” SAS, SATA, or SSD + two PCIe SSD
SLOTS
3 PCIe slots:
Two x16 slots with x16 bandwidth, half-height, half-length
One x16 slot with x8 bandwidth, half-height, half-length
Note: ten-drive-bay configuration is available only with 3 PCIe slot option
2 PCIe slots:
One x16 slot with x16 bandwidth, full-height, 3/4 length
One x16 slot with x16 bandwidth (or x8 with one processor only), half-height, half-length
RAID
Internal controllers:
PERC S110 (SW RAID)
PERC H310
PERC H710
PERC H710P
External HBAs (RAID):
PERC H810
External HBAs (non RAID):
6Gbps SAS HBA
COMMUNICATIONS
Broadcom® 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload)
Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload)
Intel X540 dual-port 10GbE Base-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports)
Broadcom 57800S dual-port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
Broadcom 57800S dual-port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
Broadcom 57840S quad-port 10GbE SFP+ Rack NDC (NPAR1.0, SRIOV, DCB, iSCSI and FCoE offloads and CEM)
POWER
Titanium efficiency, hot-plug redundant 750W power supply
Platinum efficiency, hot-plug redundant 495W, 750W or 1100W power supplies
Auto-ranging power supplies
AVAILABILITY
High-efficiency, hot-plug, redundant power supplies
DC power supplies
Hot-plug hard drives
TPM
Dual internal SD support
Hot-plug redundant fans
Optional bezel
Luggage tag
ECC memory
Interactive LCD screen
Extended thermal support
ENERGY STAR® compliant
Extended power range
Switch Agnostic Partitioning (SWAP)
CHASSIS
1U Rack
MANAGEMENT
Remote management:
iDRAC7 with Lifecycle Controller
iDRAC7 Express (default)
iDRAC7 Enterprise (upgrade)
8GB vFlash media (upgrade)
16GB vFlash media (upgrade)
Systems management:
IPMI 2.0 compliant
Dell OpenManage™ Essentials
Dell OpenManage Power Center
Dell OpenManage Connections:
Dell OpenManage Integration Suite for Microsoft® System Center
Dell plug-in for VMware® vCenter™
HP Operations Manager
IBM Tivoli® Netcool®
CA Network and Systems Management
RACK SUPPORT
ReadyRails II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks
