Servidor HP Proliant DL360 (G6)

Description

The HPE ProLiant DL360 Gen6 server is a 1U rack optimized system designed to deliver scalable performance for large databases and SMBs. Energy efficiency has been improved with high-efficient/right-sized power supplies, 32 thermal sensors throughout the server, and lower power processors. Redundant power supplies and fans, along with mirrored memory and embedded RAID capabilities, reduce server downtime and increase system fault tolerance.

Performance

Powered by Intel’s 5520 chipset, this system can support a maximum of two Intel Xeon 5500 or 5600 series processors. Six, quad, and dual-core processor models are available depending on your processing power needs. Most processor models can support Intel’s Hyper-Threading and Turbo Boost technologies. The former enables a single processor to act like two separate processors to the operating system and applications, and the latter accelerates processor performance to allow cores to run faster than the rated operating frequency.

Memory

Each processor socket contains three memory channels that support three DIMMs each. In a dual-processor configuration, this system can support up to 18 DIMM slots and a maximum memory capacity of 192GB. To achieve this capacity, six DIMM slots need to remain empty to fit twelve 16GB DDR3 registered (RDIMM) memory modules. Using unbuffered (UDIMM) memory modules will provide a maximum memory capacity of 48GB with twelve 4GB modules.

Storage

The HPE DL360 Gen6 can support a maximum of eight small form factor (SFF) drive bays with two processors installed. A four drive bay configuration has room for an optional optical drive, whereas the eight bay configurations can only support an external optical drive. With 600GB SAS drives in all eight bays, a maximum storage capacity of 4.8TB is provided. HPE’s Smart Array P410i storage controller provides increased bandwidth and quicker access to data than its predecessor.

Expansion

One low profile slot, and one full-length/full-height slot are supported on this server for a total of two PCIe expansion slots. The full-length/full-height slot can support PCI-X technology with the addition of a PCI-X riser. Four USB 2.0 ports are provided, with two in the back of the chassis, one internal, and one on the front of the system.

Management

HPE’s Integrated Lights-Out 2 (iLO2) operates without any additional software and allows administrators to remotely manage basic server tasks reducing the need for onsite support. The iLO2 browser interface is easy to navigate with similar tasks grouped together and organized under tabs across the top of the screen. Operational costs are reduced by up to 40% with HPE’s Insight Dynamics, an advanced product option that automates common data center tasks.

Summary

The HPE ProLiant DL360 Gen6 server provides flexible I/O alternatives, an impressive memory footprint, and enhanced remote management features. Server-level power management is provided with HPE’s Power Regulator to improve the system’s energy efficiency. Smart Array storage controllers deliver faster access to data, and Intel’s 5520 chipset supports QuickPath technology to further speed up data movement. A 192GB max memory footprint, 4.8TB of internal storage, and advanced thermal management capabilities make this rack server the perfect solution for both enterprise and SMB applications.

PROCESSOR – 2 SOCKETS

• Intel® Xeon® X5500 and X5600 processor product families

• Intel® Xeon® E5500 processor product family

OPERATING SYSTEMS AND VIRTUALIZATION SOFTWARE SUPPORT FOR PROLIANT SERVERS

• Microsoft Windows Server
• Microsoft Windows Server Hyper-V
• Red Hat Enterprise Linux (RHEL)
• SUSE Linux Enterprise Server (SLES)
• Oracle Solaris
• NetWare
• VMware
• Citrix XenServer

CHIPSET

MEMORY

• Type
  • DDR3 Registered (RDIMM) or Unbuffered (UDIMM)

Standard (Performance Models)

• • 12GB (6 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs

Standard (Base Models)

• • 6GB (3 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs

Standard (Entry Model)

• • 4GB (2 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs

Standard (High Efficiency Model)

• • 4GB (2 x 2GB) PC3-10600E (DDR3-1333) Unbuffered DIMMs

Maximum (RDIMM)

• • 192GB (12 x 16GB) for Registered Memory configurations

Maximum (UDIMM)

• 48GB (12 x 4GB) for Unbuffered Memory configurations

NETWORK CONTROLLER

EXPANSION SLOTS

Expansion Slot #	Technology	Bus Width	Connector Width	Bus Number	Form Factor
1	PCI-e	X8	X8	4	Low profile slot
2	PCI-e	X16	X16	7	Full-length, full height slot
2	PCI-X	64-bit	x8	7

STORAGE CONTROLLER

• Entry Models
  • HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)

Base Models

• • HP Smart Array P410i/256 MB Controller (RAID 0/1/1+0/5/5+0)

Performance Models

• • HP Smart Array P410i/512 MB BBWC Controller (RAID 0/1/1+0/5/5+0)

High Efficiency Models

• HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)

INTERNAL STORAGE DEVICES

• Diskette Drive
  • None

Optical Drive

• • None Standard
  • Optional DVD-ROM, DVD-RW or Slimline floppy drive
  • Optional HP External USB CD/DVD R/RW for 8 drive models

Hard Drives

• • None Standard

Drive Bays

• 4 SFF Drive Bays standard with options for up to 8 SFF drive bays total

MAXIMUM INTERNAL STORAGE

Hot Plug SAS	4.8TB	8 x 600GB SAS
Hot Plug SATA	4.0TB	8 x 500GB SATA

INTERFACES

• Serial
  • 1

Video

• • 1

Network RJ-45

• • 2

iLO 2 remote management port

• • 1

Keyboard (PS/2)

• • 1

Pointing Device (PS/2)

• • 1

SD slot

• • 1

USB 2.0 Ports

• 4 total: 2 rear, 1 front, 1 internal

SYSTEM FANS

• 1P Models: 3 fan modules ship standard

• 2P Models: 4 fan modules ship standard

GRAPHICS

• Integrated ATI ES1000, 32MB video standard

CHASSIS

HP INSIGHT MANAGEMENT

• HP Insight Foundation
• HP Integrated Lights-Out 2 (iLO 2)

SECURITY

• Power-on password
• Keyboard password
• Diskette drive control
• Diskette boot control
• QuickLock, Network Server Mode
• Removable CD and Diskette Drive Assembly
• Serial interface control
• Administrator’s password
• Integrated Lights-Out has 12 customizable user accounts and SSL encryption
• Integrated Lights-Out can be disabled via a Global Setting
• iLO Advance Pack supports directory services integration and two-factor authentication
