Servidor HP Proliant ML350 (G9)

Aluguel, locação e comodato
HP Proliant ML350 (G9)
Overview
Specification
Documentation

Description

hpe ML350 gen9 front perspective with bezel

The HPE ProLiant ML350 Gen9 tower server can be used as either a tower server or as a rack mounted server. It features Intel’s Xeon E5-2600 v3 and v4 processor family, and up to 24 DIMM slots, nine PCIe slots, 1GbE or 10GbE adapters, eight USB ports, and supports up to four GPU graphics or compute accelerators. It will more than accommodate your current requirements with a single processor, yet can easily expand to support dual processors.

Performance

This 5U platform features Intel’s C610 chipset and supports either one or two Xeon E5-2600 v3, or E5-2600 v4 processors with up to 22 cores. HPE SmartMemory provides a 14% percent gain in throughput. Further performance gains are had under the roof of the ML350 by providing you with support for 12GB/s serial-attached SCSI (SAS). You can further augment the system by utilizing nine 3.0 PCIe slots. For graphic performance with a standard configuration, the integrated Matrox G200 delivers 32-bit color with 256MB DDR3.

Memory

The HPE ML350 Gen9 tower server uses the latest quad channel DDR4 memory operating at speeds of up to 2400MHz. With dual E5-2600 v4 processors, and all 24 slots loaded with 128GB Load Reduced (LRDIMM) modules, the system can support up to 3TB of memory. With E5-2600 v3 modules, the system will support a maximum of 1.5TB of memory using 64GB LRDIMM modules. HPE recommends using HPE Smart Memory, which features a patented memory design process to ensure advanced error correction at all levels.

Storage

There are plenty of storage options with the HPE ML350 Gen9 tower server, which can max out at an astounding 144TB using 24LFF x 6TB SAS hard drives. The system will support a maximum of 48 2.5-inch SFF drives, or up to 24 3.5-inch LFF SATA or SAS SSDs or HDDs drives. Up to 6SFF NVMe PCIe SSD drives are also supported. This system comes standard with the HP Dynamic Smart Array B140i, or for performance applications the Smart Array P440ar/2G.

Expansion

hpe ML350 gen9 server power supply

With a standard configuration, this system features an HPE embedded 331i with four 1GbE ports. However, you can enhance your operation by upgrading from a wide selection of HP Flexible Smart Array’s or Smart HBA controllers. There are eight PCIe 3.0 slots and one PCIe 2.0 slot, meaning ample room for more video cards, NICs, and storage controllers. For graphic performance with a standard configuration, an integrated Matrox G200 delivers 32-bit color with 256MB DDR3. Administrators can also choose from a selection of graphics and computational accelerators including the Nvidia Quadro M5000, Tesla K40 and the AMD W7100 accelerator.

Management

HPE’s iLO Management suite offers comprehensive and innovative tools, which include HP Insight Online, HP Insight Control, HP OneView, and HP Smart Update. Server health can be monitored just about anywhere using a standard browser connection, or directly on site using the command line. HPE’s iLO Advanced license provides a remote console, virtual keyboard, video, mouse, multi-user collaboration and much more. HPE Provisioning will vastly improve deployment times, making server configuration and deployment a breeze. HP Smart Update automates I/O card and platform firmware updates to help reduce downtime. System insight display is only available on the rack mount configuration.

Summary

Whether an SMB, remote office, or a data center, IT environments are often complex and fast changing. By deploying the HPE ProLiant ML350 Gen9 server you gain a competitive advantage that offers increased performance, more options for expandability, greater flexibility, stronger reliability, and state of the art automated server management.

PROCESSOR – 2 SOCKETS
    Intel® Xeon® processor E5-2600v3 and E5-2600v4 product families
OPERATING SYSTEMS AND VIRTUALIZATION SOFTWARE SUPPORT FOR PROLIANT SERVERS
  • Microsoft Windows Server
  • Canonical Ubuntu
  • Red Hat Enterprise Linux (RHEL)
  • SUSE Linux Enterprise Server (SLES)
  • VMware
  • Citrix XenServer
  • ClearOS
CHIPSET
    Intel® C610 Series Chipset
ON SYSTEM MANAGEMENT CHIPSET
    HPE iLO (Firmware HPE iLO4 2.0 or later) 4GB NAND
MEMORY
    • Type

    • DDR4 Registered (RDIMM) or Load Reduced (LRDIMM)

DIMM Slots Available

    • 24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)

Maximum Capacity (LRDIMM)

    • 1.5TB (24 x 64GB LRDIMM) with E5-2600v3 processors
    • 3TB (24 x 128GB LRDIMM) with E5-2600v4 processors

Maximum Capacity (RDIMM)

  • 768GB (24 x 32GB RDIMM)
NETWORK CONTROLLER
    HPE 1Gb Ethernet 4-port 331i Adapter
EXPANSION SLOTS
Expansion Slot # Technology Bus Width Connector Width Bus Number Form Factor
9 PCIe 3.0 X4 X8   Full-height, full-length slot
8 PCIe 3.0 X16 X16   Full-height, full-length slot
7 PCIe 3.0 X4 X8   Full-height, full-length slot
6 PCIe 3.0 X16 X16   Full-height, full-length slot
5 PCIe 2.0 X4 X8   Full-height, half-length slot
4 PCIe 3.0 X4 X8 0 Full-height, full-length slot
3 PCIe 3.0 X16 X16 0 Full-height, full-length slot
2 PCIe 3.0 X4 X8 0 Full-height, half-length slot
1 PCIe 3.0 X8 X16 0 Full-height, full-length slot
STORAGE CONTROLLER
    • Entry Models

    • HPE Dynamic Smart Array B140i Embedded SATA controller

Base Models

    • HPE Flexible Smart Array P440ar/2GB

Performance Models

  • HPE Flexible Smart Array P440ar/2GB
INTERNAL STORAGE DEVICES
    • Optical Drive

    • Optional SATA 9.5mm DVD-ROM Optical Drive
    • Optional SATA 9.5mm DVD RW Optical Drive

Hard Drive Bays

    • 8 Hot plug SFF SAS/SATA HDD bays; upgradable to 48
    • 8 Hot plug LFF SAS/SATA HDD Bays; upgradable to 24

Hard Drives

  • None ship standard
MAXIMUM INTERNAL STORAGE
Hot Plug LFF SAS 240TB 24 x 10TB
Hot Plug LFF SATA 240TB 24 x 10TB
Hot Plug LFF SAS SSD 38.4TB 24 x 1.6TB
Hot Plug LFF SATA SSD 92.16TB 24 x 3.84TB
Hot Plug SFF SAS 96TB 48 x 2TB
Hot Plug SFF SATA 96TB 48 x 2TB
Hot Plug SFF SAS SSD 184.32TB 48 x 3.84TB
Hot Plug SFF SATA SSD 184.32TB 48 x 3.84TB
Hot Plug SFF NVMe PCIe SSD 7.2TB 6 x 1.2TB
POWER SUPPLY
  • HPE 500W Flex Slot Platinum Hot Plug Power Supply
  • HPE 800W Flex Slot Platinum Hot Plug Power Supply
  • HPE 1400W Flex Slot Platinum Plus Hot Plug Power Supply
SYSTEM FANS
  • 1P model: 3 non-redundant fans, 6 redundant fans
  • 2P model: 4 non-redundant fans, 8 redundant fans
INTERFACES
    • Serial

    • 1

Video

    • 1 (rear)

Network RJ-45 (Ethernet)

    • 4

HP iLO Remote Management Network Port

    • 1 Gb Dedicated

SD slot

    • 1 (internal)

USB 2.0 Ports

    • 5 (2 front, 2 rear, 1 internal)

USB 3.0

  • 3 (2 rear, 1 internal)
GRAPHICS
    Integrated Matrox G200 video standard
CHASSIS
    Tower or Rack (5U)
EMBEDDED MANAGEMENT
  • HPE Integrated Lights-Out (HPE iLO)
  • UEFI
  • RESTful API
  • Intelligent Provisioning
  • Embedded Remote Support
SERVER UTILITIES
  • Smart Update
  • HPE Systems Insight Manager (HPE SIM)
  • Scripting Tool Kit and Windows PowerShell
  • RESTful Interface Tool
  • HPE iLO Mobile Application
  • HPE Insight Online
SECURITY
  • Power-on password
  • Setup password
  • Serial interface control
  • Power switch security
  • Administrator’s password
  • UEFI
  • TPM 1.2
  • TPM 2.0
  • Security Front Bezel
  • Chassis mechanical support of padlock and Kensington Security lock (located at system rear)
