FortiAP-23JF |
| Hardware Type |
Outdoor AP |
| Number of Radios |
3 + 1 BLE |
| Number of Antennas |
4 dual band WiFi + 1 dual band scanning + 1 single band 2.4 GHz BLE/ZigBee |
| Antenna Type and Peak Gain |
WiFi and scanning radio dual band antenna: 5.5 dBi in 2.4 GHz and 7.2 dBi in 5 GHz band
BLE antenna: 5.0 dBi in 2.4 GHz band |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Radio 1 Capabilities |
Frequency band: 2.4 GHz
Channel width: 20/40MHz
Modulation: BPSK, QPSK, 64/256/1024 QAM
MIMO Chains: 4×4 Service |
| Radio 2 Capabilities |
Frequency band: 5.0 GHz
Channel width: 4×4 20/40/80MHz and 2×2 160 MHz contiguous
Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024
MIMO Chains: 4×4 Service |
| Radio 3 Capabilities |
Frequency bands: 2.4 GHz and 5.0 GHz
MIMO Chains: 1×1 Frequency Scanning |
| Maximum Data Rate |
Radio 1: up to 1147 Mbps
Radio 2: up to 2402 Mbps
Radio 3: Frequency scanning only |
| Bluetooth Low Energy Radio |
Bluetooth scanning and iBeacon advertisement @ 10 dBm max TX power |
| Interfaces |
1x 10/100/1000/2500 Base-T RJ45,1 x 10/100/1000 Base-T RJ45 (802.3af PoE PSE),1x Type A USB, 1x RS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) |
1 x 802.3bt PoE default
Operational modes: No 802.3af support ; 1 x 802.at Operates in reduced power (17dBm) R1 & R2 in 4×4 chain. |
| Simultaneous SSIDs |
Up to 16 (14 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™, WPA2™, and WPA3™ with 802.1x or preshared key, WEP, Web Captive Portal, MAC blocklist & allowlist |
| Maximum Tx Power (Conducted) |
Radio 1: 2.4 GHz 30 dBm / 1000 mW (4 chains combined)
Radio 2: 5 GHz 26 dBm / 398 mW (4 chains combined)
Radio 3: N/A |
| Kensington Lock |
Yes |
| IEEE Standards |
802.11a, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bt, 802.3bz |
| Per Radio Client Capacity |
Up to 512 clients per radio (Radio1 and Radio2) |
| Cellular Co-existence |
Yes |
| LED Off Mode |
Yes |
| OFDMA |
Yes (UL and DL) |
| Spatial Reuse (BSS Coloring) |
Yes |
| UL MU-MIMO 802.11ax mode |
Yes |
| DL-MU-MIMO |
Yes |
| Enhanced Target Wake Time (TWT) |
Yes |
| ZeroWait DFS/Agile DFS |
Yes |
| Rogue Scan radio modes |
Background, Dedicated |
| WIPS / WIDS radio modes |
Background, Dedicated (recommended) |
| Packet Sniffer Mode |
Yes |
| Spectrum Analyzer |
Yes |
| Length x Width x Height |
8.23 x 8.23 x 2.38 inches (209 x 209 x 60.5 mm) |
| Weight |
5.12 lbs (2.325 kg) |
| Package (shipping) Weight |
12.56.93 lbs (5.7 kg) |
| Mounting Options |
Ceiling, T-Rail, and Wall |
| Included Accessories |
Standard Mount kit for Ceiling, T-Rail, and Wall |
| Power Supply |
802.3bt PoE, ships with PoE injector (reset functionality) |
| Power Consumption (Maximum) |
25 W without PSE out and 37.9 W with PSE out |
| PSE functionality |
Yes (while powered by PoE injector shipped with product) |
| Humidity |
10 – 90% non condensing |
| Operating / Storage Temperature |
-22–140°F (-30 – 60°C) / -40–176°F (-40–80°C) |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
No |
| Mean Time Between Failures |
> 10 Years |
| IP Rating |
IP67 |
| Surge Protection Built In |
Yes |
| Hit-less PoE Failover |
N/A |
| WiFi Alliance Certified |
No |
| DFS |
No |
| Limited Lifetime Warranty |
Yes |
