The FortiGate/FortiWiFi-60D-3G4G series of consolidated security appliances deliver comprehensive enterprise-class protection for smaller locations, branch offices, customer premise equipment (CPE) and retail networks. The embedded 3G/4G wireless modem provides a cost-effective and rapidly deployable WAN connectivity option that reduces network complexity and increases network uptime. Simple per-device pricing, an integrated management console, and remote management capabilities significantly reduce your procurement, deployment and administration costs.
FortiGate/FortiWiFi-60D-3G4G-VZW sports an embedded wireless wan module for 3G/4G mobile data applications. Powered by Qualcomm® MDM9600 chipset, this FortiWiFi platform offers high performance Internet connectivity on LTE 700 MHz with fallback to CDMA and HSPA+/UMTS and is certified for Verizon Wireless Network in US.
FortiGate consolidated security appliances deliver an unmatched range of security technologies. They integrate essential firewall, IPSec and SSL VPN, application control, intrusion prevention, antivirus, and web filtering protection into a single device at a single price, all managed from a “single-pane-of-glass” console. They also include other security technologies, such as data loss prevention (DLP), encrypted SSL inspection, endpoint NAC, WAN optimization, and vulnerability management. In addition, Fortinet’s FortiGuard® Labs is on duty around the clock and around the world, monitoring changes in the threat landscape. FortiGuard Labs deliver dynamic threat updates to protect your network against emerging threats.
| Unified Security Architecture | Multi-threat protection from a single device increases security and lowers costs |
| Simple Licensing | Hassle-free unlimited user licensing and comprehensive feature set increases ease of deployment and maintenance |
| Multi-Port Interfaces | Multiple network interfaces and optional wireless connectivity enables flexible deployment and improves protection with multiple security zones |
The FortiExplorer™ wizard enables you to easily and quickly set up and configure FortiGate and FortiWiFi platforms with easy-to-follow instructions. The application runs on Windows, Mac OS X desktops and laptops as well as popular mobile devices. Simply connect to the appropriate USB port on the appliance, and be fully protected in minutes.
The FortiGate/FortiWiFi-60D-3G4G includes a built-in 3G/4G modem that allows additional WAN connectivity or a redundant link for maximum reliability.
Designed for small environments, you can place it on a desktop or wall-mount it. It is small, lightweight yet highly reliable with superior MTBF (Mean Time Between Failure), minimizing the chance of a network disruption.
A built-in dual-band, dual-stream access point with internal antennas is integrated on the FortiWiFi-60D and provides speedy 802.11n coverage on both 2.4 GHz and 5 GHz bands. The dual-band chipset addresses the PCI-DSS compliance requirement for rogue AP wireless scanning, providing maximum protection forregulated environments.
The FortiGate family of physical and virtual appliances has earned more certifications than any other vendor by consistently meeting rigorous third-party standards. Our industry-leading technology provides you with air-tight security which you can safely count on.
The FortiGate constantly evolves itself in its mission to provide more value for users. Extended features such as WiFi controller, integrated token server, endpoint control and WAN optimization add more security to organizations without incurring additional cost.
Fortinet FortiGuard Subscription Services provide automated, real-time, up-to-date protection against the latest security threats. Our threat research labs are located worldwide, providing 24×7 updates when you most need it.
Fortinet FortiCare support offerings provide comprehensive global support for all Fortinet products and services. You can rest assured your Fortinet security products are performing optimally and protecting your users, applications, and data around the clock.
| FG-60D-3G4G-VZW | FWF-60D-3G4G-VZW | |
|---|---|---|
| Interfaces & Modules | ||
| 10/100/1000 WAN Interfaces (RJ45) | 2 | |
| 10/100/1000 Internal Interfaces (RJ45) | 7 | |
| 10/100/1000 DMZ Interfaces (RJ45) | 1 | |
| Wireless Interface | – | 802.11 a/b/g/n |
| USB (Client / Server) | 1/1 | |
| RJ-45 Console Port | 1 | |
| Embedded Modem | ||
| Embedded Modem technology | LTE with fallback to EV-DO Rev A, 1xRTT | |
| Bands | LTE AWS, 700 MHz (B17) (with MIMO) HSPA+/UMTS 850/AWS/1900/2100 MHz GPRS 850/900/1800/1900 MHz | |
| MiMo | 2 x 2 MiMo | |
| Receiver Diversity | Yes, improves performance at cell edges and in buildings | |
| Receiver Equalization | Yes, improves performance in noisy and highly mobile environments | |
| Internal antennas | 2 | |
| Supported LTE band | 13 | |
| Removable SIM card | Yes | |
| Signal strength indicator | Yes, in FortiOS GUI and CLI | |
| DIAG & AT commands | Yes | |
| Auto-Connect / On Demand Connect | Yes | |
| Power Management | Standby & hibernate selective suspend | |
| Other features | Connection status, data byte count, auto-select network, network profile, self diagnostics, private IP SIM support, IMEI located on outer box and device for easy activation | |
| System Performance & Capacity | ||
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 1.5 / 1.5 / 1.5 Gbps | |
| Firewall Latency (64 byte, UDP) | 4 μs | |
| Firewall Throughput (Packet per Second) | 2.2 Mpps | |
| Concurrent Sessions (TCP) | 500,000 | |
| New Sessions/Sec (TCP) | 4,000 | |
| Firewall Policies | 5,000 | |
| IPSec VPN Throughput (512 byte) | 1 Gbps | |
| Gateway-to-Gateway IPSec VPN Tunnels | 200 | |
| Client-to-Gateway IPSec VPN Tunnels | 500 | |
| SSL VPN Throughput | 30 Mbps | |
| Concurrent SSL-VPN Users (recommended Max) | 100 | |
| IPS Throughput | 200 Mbps | |
| Antivirus Throughput (Proxy Based / Flow Based) | 35 / 50 Mbps | |
| Virtual Domains (Default / Max) | 10 / 10 | |
| Max Number of FortiAPs (Total / Tunnel) | 10 / 5 | |
| Max Number of FortiTokens | 100 | |
| Max Number of Registered Endpoints | 200 | |
| High Availability Configurations | Active-Active, Active-Passive, Clustering | |
| Dimensions & Power | ||
| Height x Width x Length | 1.50 x 8.50 x 5.83 in (38 x 216 x 148 mm) | |
| Weight | 1.9 lbs (0.9 kg) | |
| Form Factor | Desktop | |
| AC Power Supply | 100-240 VAC, 50-60 Hz | |
| Power Consumption (Avg / Max) | 11.7 / 14 W | |
| Heat Dissipation | 40 BTU/h | |
| Operating Environment & Certifications | ||
| Operating Temperature | 32 – 104 deg F (0 – 40 deg C) | |
| Storage Temperature | -31 – 158 deg F (-35 – 70 deg C) | |
| Humidity | 20 to 90% non-condensing | |
| Compliance | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB, RoHS, Halogen Free | |
| Security Certifications | ICSA Labs: Firewall, IPSec, IPS, Antivirus, SSL VPN | |
| Other Certifications | Certified for use on Verizon Network, 3GPP TS 36.101 (LTE), 3GPP Rel 5, 6, 7, 8 (HSPA+), 3GPP Release 99 (GSM/GPRS/EDGE), CCF57, PTCRB, SUPL 2.0 | |
Download the Fortinet FortiGate/FortiWiFi 60D-3G4G-VZW Datasheet (PDF).
| Licença | Fortinet FortiGate-60D-3G4G-VZW Enterprise Protection | |
|---|---|
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year Enterprise Protection (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam, Security Rating, Industrial Security, FortiConverter Svc, and FortiCare Premium) | #FC-10-0066D-810-02-12 |
| Licença | FortiGate-60D-3G4G-VZW 24×7 Unified Threat Protection (UTP) | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam Service, and FortiCare Premium) | #FC-10-0066D-950-02-12 |
| Licença | FortiGate-60D-3G4G-VZW FortiCare Premium Support | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiCare Premium Support | #FC-10-0066D-247-02-12 |
| Licença | FortiGate-60D-3G4G-VZW Upgrade FortiCare Premium to Elite | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year Upgrade FortiCare Premium to Elite (Require FortiCare Premium) | #FC-10-0066D-204-02-12 |
| Licença | FortiGate-60D-3G4G-VZW FortiCare Elite Support | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiCare Elite Support | #FC-10-0066D-284-02-12 |
| Licença | FortiGate-60D-3G4G-VZW Advanced Threat Protection | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year Advanced Threat Protection (IPS, Advanced Malware Protection Service, Application Control, and FortiCare Premium) | #FC-10-0066D-928-02-12 |
| Licença | FortiGate-60D-3G4G-VZW Services | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiGate Cloud Sandbox Service | #FC-10-0066D-100-02-12 |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiGuard IPS Service | #FC-10-0066D-108-02-12 |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiGuard URL, DNS & Video Filtering Service | #FC-10-0066D-112-02-12 |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiGuard Industrial Security Service | #FC-10-0066D-159-02-12 |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiGuard Security Rating Service | #FC-10-0066D-175-02-12 |
| Licença | Fortinet FortiGate-60D-3G4G-VZW FortiCloud Management, Analysis and 1 Year Log Retention | |
| 1 ano – FortiGate-60D-3G4G-VZW 1 Year FortiGate Cloud Management, Analysis and 1 Year Log Retention | #FC-10-0066D-131-02-12 |
