The FortiGate 7121F series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high port density, and high throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network performance. Fortinet’s security-driven networking approach provides tight integration with the new security generation.
Firewall | IPS | NGFW | Threat Protection | Interfaces |
1.89 Tbps | 675 Gbps | 550 Gbps | 520 Gbps | 25 GE SFP28 / 10 GE SFP+ / GE SFP 100 GE QSFP28 / 40 GE QSFP+ 400 GE QSFP-DD |
Fortinet’s ninth generation custom SPU CP9 content processor works outside of the direct flow of traffic and accelerates the inspection.
Fortinet’s new, breakthrough SPU NP7 network processor works inline with FortiOS functions delivering:
The FortiGate 7121F Series features a dedicated module that hardens physical networking appliances by generating, storing, and authenticating cryptographic keys. Hardwarebased security mechanisms protect against malicious software and phishing attacks.
FortiGuard’s rich suite of security services counter threats in real time using AI-powered, coordinated protection designed by FortiGuard Labs security threat researchers, engineers, and forensic specialists.
Advanced cloud-delivered URL, DNS (Domain Name System), and Video Filtering providing complete protection for phishing and other web born attacks while meeting compliance.
Additionally, its dynamic inline CASB (Cloud Access Security Broker) service is focused on securing business SaaS data, while inline ZTNA traffic inspection and ZTNA posture check provide per-sessions access control to applications. It also integrates with the FortiClient Fabric Agent to extend protection to remote and mobile users.
Advanced content security technologies enable the detection and prevention of known and unknown threats and file-based attack tactics in real-time. With capabilities like CPRL (Compact Pattern Recognition Language), AV, inline Sandbox, and lateral movement protection make it a complete solution to address ransomware, malware, and credential-based attacks.
Advanced security technologies are optimized to monitor and protect IT, IIoT, and OT (Operational Technology) devices against vulnerability and device-based attack tactics. Its validated near-real-time IPS intelligence detects, and blocks known and zero-day threats, provides deep visibility and control into ICS/OT/SCADA protocols, and provides automated discovery, segmentation, and pattern identification-based policies.
Advanced NOC and SOC management tools attached to your NGFW provide simplified and faster time-to-activation.
Includes tier-one hunting and automation, log location, 24×7 SOC analyst experts, managed firewall and endpoint functions, and alert triage.
Includes supply chain virtual patching, up-to-date risk and vulnerability data to deliver quicker business decisions, and remediation for data breach situations.
Traditional firewalls cannot protect against today’s content- and connection-based threats because they rely on off-the-shelf hardware and general-purpose CPUs, causing a dangerous performance gap. Fortinet’s custom SPU processors deliver the power you need—up to 520Gbps—to detect emerging threats and block malicious content while ensuring your network security solution does not become a performance bottleneck.
Network Processors operate inline to deliver unmatched performance and scalability for critical network functions. Fortinet’s breakthrough SPU NP7 network processor works in line with FortiOS functions to deliver:
Content Processors act as co-processors to offload resource-intensive processing of security functions. The ninth generation of the Fortinet Content Processor, the CP9, accelerates resource-intensive SSL (including TLS 1.3) decryption and security functions while delivering:
Fortinet is dedicated to helping our customers succeed, and every year FortiCare Services help thousands of organizations get the most from our Fortinet Security Fabric solution. Our lifecycle portfolio offers Design, Deploy, Operate, Optimize, and Evolve services. Operate services offer device-level FortiCare Elite service with enhanced SLAs to meet our customer’s operational and availability needs. In addition, our customized account-level services provide rapid incident resolution and offer proactive care to maximize the security and performance of Fortinet deployments.
FortiGate 7121F | |
---|---|
Interfaces and Modules | |
Hardware Accelerated 400 GE QSFP-DD / 100 GE QSFP28 / 40 GE QSFP+ Slots | 4 |
Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots | 56 |
Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Management/HA Slots | 4 |
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Slots | 80 |
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ SFP Management/HA Slots | 4 |
GE RJ45 Management Ports | 4 |
USB Ports | 2 |
Console Ports | 14 |
Onboard Storage | 4x 4 TB SSD |
Included Transceivers | 4x 10 GE SFP+ SR |
System Performance – Enterprise Traffic Mix | |
IPS Throughput2 | 675 Gbps |
NGFW Throughput2, 4 | 550 Gbps |
Threat Protection Throughput2, 5 | 520 Gbps |
System Performance and Capacity | |
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP packets) | 1.89 / 1.88 / 1.129 Tbps |
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP packets) | 1.89 / 1.88 / 1.129 Tbps |
Firewall Latency (64 byte, UDP) | 7.50 μs |
Firewall Throughput (Packet per Second) | 1680 Mpps |
Concurrent Sessions (TCP) | 1 Billion |
New Sessions/Sec (TCP) | 9 Million |
Firewall Policies | 200 000 |
IPsec VPN Throughput (512 byte)6 | 630 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels | 40 000 |
Client-to-Gateway IPsec VPN Tunnels | 260 000 |
SSL-VPN Throughput7 | 13.7 Gbps |
Concurrent SSL-VPN Users (Recommended Maximum) | 30 000 |
IPS Throughput (Enterprise Mix)1 | 675 Gbps |
SSL Inspection Throughput2 | 540 Gbps |
SSL Inspection CPS (IPS, avg. HTTPS)3 | 480 000 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS)3 | 100 Million |
Application Control Throughput3 | 1.5 Tbps |
NGFW Throughput4 | 550 Gbps |
Threat Protection Throughput5 | 520 Gbps |
CAPWAP Throughput | N.A. |
Virtual Domains (Default / Maximum) | 10 / 500 |
Maximum Number of FortiTokens | 20 000 |
Maximum Number of FortiSwitches Supported | 300 |
Maximum Number of FortiAPs (Total / Tunnel Mode) | N.A. |
High Availability Configurations | Active-Passive, Active-Active |
Dimensions and Power | |
Height x Width x Length (inches) | 28.63 x 17.33 x 26.6 |
Height x Width x Length (mm) | 727.2 x 440 x 675.5 |
Weight (maximum) | 447.36 lbs (203.1 kg) |
Form Factor (supports EIA/non-EIA standards) | 16 RU 10 Slots for FPM and 2 Slots for FIM (default configuration 2xFPM-7620F and 2xFIM-7921F) |
Power Required | 200 to 240 VAC (50/60 Hz) |
Power Consumption (Maximum / Average) | 9754 W / 8296 W |
AC Current (Maximum) | 8 x 10A |
Heat Dissipation (Maximum) | 33 261 BTU/h |
Operating Environment and Certifications | |
Operating Temperature | 32–104°F (0–40°C) |
Storage Temperature | -31–158°F (-35–70°C) |
Humidity | 20–90% non-condensing |
Compliance | |
Certifications | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
Download the Fortinet FortiGate 7121F Series Data Sheet (PDF).
Hardware | FortiGate 7121F-2 Base Appliance | |
---|---|
FortiGate 7121F-2 | #FG-7121F-2 |
Licença | FortiGate 7121F-2 Enterprise Protection | |
1 ano – FortiGate-7121F-2 1 Year Enterprise Protection (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam, Security Rating, IoT Detection, Industrial Security, FortiConverter Svc, and FortiCare Premium) | #FC-10-F7CF2-811-02-12 |
3 anos – FortiGate-7121F-2 3 Year Enterprise Protection (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam, Security Rating, IoT Detection, Industrial Security, FortiConverter Svc, and FortiCare Premium) | #FC-10-F7CF2-811-02-36 |
5 anos – FortiGate-7121F-2 5 Year Enterprise Protection (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam, Security Rating, IoT Detection, Industrial Security, FortiConverter Svc, and FortiCare Premium) | #FC-10-F7CF2-811-02-60 |
Licença | FortiGate 7121F-2 Unified Threat Protection (UTP) | |
1 ano – FortiGate-7121F-2 1 Year Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam Service, and FortiCare Premium) | #FC-10-F7CF2-950-02-12 |
3 anos – FortiGate-7121F-2 3 Year Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam Service, and FortiCare Premium) | #FC-10-F7CF2-950-02-36 |
5 anos –FortiGate-7121F-2 5 Year Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, URL, DNS & Video Filtering, Antispam Service, and FortiCare Premium) | #FC-10-F7CF2-950-02-60 |
Licença | FortiGate 7121F-2 FortiCare Premium Support | |
1 ano – FortiGate-7121F-2 1 Year FortiCare Premium Support | #FC-10-F7CF2-247-02-12 |
3 anos – FortiGate-7121F-2 3 Year FortiCare Premium Support | #FC-10-F7CF2-247-02-36 |
5 anos – FortiGate-7121F-2 5 Year FortiCare Premium Support | #FC-10-F7CF2-247-02-60 |
Licença | FortiGate 7121F-2 FortiCare Elite Support | |
1 ano – FortiGate-7121F-2 1 Year FortiCare Elite Support | #FC-10-F7CF2-284-02-12 |
3 anos – FortiGate-7121F-2 3 Year FortiCare Elite Support | #FC-10-F7CF2-284-02-36 |
5 anos – FortiGate-7121F-2 5 Year FortiCare Elite Support | #FC-10-F7CF2-284-02-60 |
Licença | FortiGate-7121F-2 Upgrade FortiCare Premium to Elite | |
1 ano – FortiGate-7121F-2 1 Year Upgrade FortiCare Premium to Elite (Require FortiCare Premium) | #FC-10-F7CF2-204-02-12 |
3 anos – FortiGate-7121F-2 3 Year Upgrade FortiCare Premium to Elite (Require FortiCare Premium) | #FC-10-F7CF2-204-02-36 |
5 anos – FortiGate-7121F-2 5 Year Upgrade FortiCare Premium to Elite (Require FortiCare Premium) | #FC-10-F7CF2-204-02-60 |
Licença | FortiGate 7121F-2 Advanced Threat Protection | |
1 ano – FortiGate-7121F-2 1 Year Advanced Threat Protection (IPS, Advanced Malware Protection Service, Application Control, and FortiCare Premium) | #FC-10-F7CF2-928-02-12 |
3 anos – FortiGate-7121F-2 3 Year Advanced Threat Protection (IPS, Advanced Malware Protection Service, Application Control, and FortiCare Premium) | #FC-10-F7CF2-928-02-36 |
5 anos – FortiGate-7121F-2 5 Year Advanced Threat Protection (IPS, Advanced Malware Protection Service, Application Control, and FortiCare Premium) | #FC-10-F7CF2-928-02-60 |
Licença | FortiGate 7121F-2 Services | |
1 ano – FortiGate-7121F-2 1 Year Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiGate Cloud Sandbox Service | #FC-10-F7CF2-100-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard IPS Service | #FC-10-F7CF2-108-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard URL, DNS & Video Filtering Service | #FC-10-F7CF2-112-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard Industrial Security Service | #FC-10-F7CF2-159-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard Security Rating Service | #FC-10-F7CF2-175-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard IoT Detection Service | #FC-10-F7CF2-231-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard SD-WAN Underlay Bandwidth and Quality Monitoring Service | #FC-10-F7CF2-288-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiAnalyzer Cloud with SOCaaS: cloud-based central logging & analytics. Include all FortiGate log types, IOC Service, Security Automation Service, FortiGuard Outbreak Detection Service and SOCaaS | #FC-10-F7CF2-464-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiConverter Service for one time configuration conversion service | #FC-10-F7CF2-189-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard AI-based Inline Sandbox Service | #FC-10-F7CF2-577-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiAnalyzer Cloud: cloud-Based central logging & analytics. Include All FortiGate log types, IOC Service, Security Automation Service and FortiGuard Outbreak Detection Service. | #FC-10-F7CF2-585-02-12 |
1 ano – FortiGate-7121F-2 1 Year FortiGuard Data Loss Prevention Service | #FC-10-F7CF2-589-02-12 |
1 ano – FortiGate-7121F-2 1 Year Managed FortiGate service, available 24×7, with Fortinet NOC experts performing device setup, network, and policy change management
|
#FC-10-F7CF2-660-02-12 |
Licença | FortiGate Cloud | |
1 ano – FortiGate Cloud / FortiLAN Cloud – 1 Year MultiTenancy Account | #FCLE-10-FCLD0-161-02-12 |
Enables zero touch bulk provisioning for your FortiGate, FortiWifi, or FortiAP products. | #FDP-SINGLE-USE |
Licença | FortiGate-7121F-2 SD-WAN Connector for FortiSASE Secure Private Access. | |
1 ano – FortiGate-7121F-2 1 Year SD-WAN Connector for FortiSASE Secure Private Access.
|
#FC-10-F7CF2-662-02-12 |
